LiNbO3
Specification:
| Material | LiNbO3 |
| transparency range | 420-5200nm |
| Orientation accuracy | ±30 arc min |
| Flatness | λ /8@633nm |
| Parallelism | 20 arc sec |
| Perpendicularity | <10 arc min |
| Clear aperture | 0.9 |
| Edge bevels | <0.2mmx45° |
| Surface quality | 10-5 Scratch/Dig (40-20 after coating) |
| No visible scattering paths or centers when inspected by a 30 mW green laser | |
| Wave front distortion | λ /8@633nm |
| coating: | AR coatings or Broad Band AR-coatings |
| Residual reflectivity: | R@1064nm<0.2%, R@532nm<0.5%, R@355nm<1% |
Standard LiNbO3
| Part no. | Dimension(mm) | Theta(deg) | Phi(deg) | Coating | Application |
| BBO001 | 4.0*4.0*7.0 | 22.8 | 0 | AR/AR@1064&532nm | SHG@1064,TypeI |
| BBO002 | 4.0*4.0*7.0 | 47.6 | 0 | AR/AR@532&266nm | FHG@1064,TypeI |
| BBO003 | 4.0*4.0*10.0 | 22.8 | 0 | AR/AR@1064&532nm | SHG@1064,TypeI |
| BBO004 | 4.0*4.0*10 | 47.6 | 0 | AR/AR@532&266nm | FHG@1064,TypeI |
| BBO005 | 5.0*5.0*2.0 | 29.2 | 0 | AR/AR@800&400nm | SHG@800,TypeI |
| BBO006 | 5.0*5.0*1.0 | 29.2 | 0 | AR/AR@800&400nm | SHG@800,TypeI |
| BBO007 | 5.0*5.0*0.3-0.5 | 29.2 | 0 | AR/AR@800&400nm | SHG@800,TypeI |
| BBO008 | 5.0*5.0*0.1 | 29.2 | 0 | AR/AR@800&400nm | SHG@800,TypeI |
